Parts No. |
Impedance Test 100MHz Typical
(Ω) |
Rated Current (mA) |
DCR
(Ω) Max. |
Rated DC (V) |
Wire Dia. (mm) |
Turns |
|
CMC 1206 - N900SQ2 |
90 |
370 |
0.30 |
50 |
0.06 |
3 |
|
CMC 1206 - N161SQ2 |
160 |
340 |
0.40 |
50 |
0.06 |
4 |
|
CMC 1206 - N261SQ2 |
260 |
310 |
0.50 |
50 |
0.06 |
5 |
|
CMC 1206 - N601SQ2 |
600 |
260 |
0.80 |
50 |
0.05 |
8 |
|
CMC 1206 - N102SQ2 |
1000 |
230 |
1.00 |
50 |
0.05 |
10 |
|
CMC 1206 - N222SQ2 |
2000 |
200 |
1.20 |
50 |
0.04 |
14 |
| |
|
|
|
|
|
|
