Parts No. |
Impedance Test 100MHz Typical
(Ω) |
Rated Current (mA) |
DCR
(Ω) Max. |
Rated DC (V) |
Wire Dia. (mm) |
Turns |
|
CMC 0805 - N670SQ2 |
67 |
400 |
0.25 |
50 |
0.05 |
3 |
|
CMC 0805 - N121SQ2 |
120 |
370 |
0.30 |
50 |
0.05 |
4 |
|
CMC 0805 - N181SQ2 |
180 |
330 |
0.35 |
50 |
0.05 |
5 |
|
CMC 0805 - N261SQ2 |
260 |
300 |
0.40 |
50 |
0.05 |
6 |
| |
|
|
|
|
|
|
